BACOENG 3CFM Vacuum Pump & Manifold Gauge Set - HVAC A/C Refrigeration Kit - Diagnostic, R32, R134a, R410A, R407C, Orange
Condition: New and unused, all components are present and in original packaging. Packaging has been opened for quality checks and resealed.
-
Vacuum Pump: Flow rate: 3CFM; Power: 1/4HP; Ultimate Vacuum: 0.8Pa.
-
Gauge Set: 2 Valve Manifold with sight-glass & 1/4inch SAE fittings anodized aluminium block body, oversized sight-glass for easy viewing the refrigerant flow high quality stainless steel gauge and high accuracy of reading.
-
Accessory: 3 x 4ft Blue Red Yellow Refrigerant Hose, 2 x Adjustable Quick Fitting, 1 x Toolkit, 1 x Manual for Pump and Gauge.
-
Hose: All hose are complied with SAE-J2196 standard standard. Hose Working pressure: 800PSI-4000PSI Acceptable refrigerant: CFC HCFC and HFC.
-
Ideal for R32 R134a R410A R407C. Newly Designed Compact Vacuum Pump, Portable and Stronger.
Product description
Vacuum Pump Specifications:
- Pumping speed: 3 CFM
- Ultimate vacuum: 0.8 Pa
- Rotating speed: 1440 Rpm
- Oil capacity: 250 ML
- Power: 1/4 HP
- Voltage: AC 220V/50HZ
- Inlet valve: 1/4'' SAE
- Size: 26 * 12 * 23 cm
- Weight: 5.5 kg
- High efficiency and Low Noise Decibels
- Heavy-duty aluminum Alloy Casing
- Direct Drive Maintenance Free Motor permitting straightforward starting
- Clear Oil Sight Glass to easily monitor Oil Level
- Internal High Volume Cooling Fan for Extended Periods of Use
- Exhaust Port with an included Exhaust Cap
Manifold Gauge Specifications:
- Hose Working pressure: 800PSI-4000PSI
- Acceptable refrigerant: CFC HCFC and HFC
- Gauge: 3 inches diameter
- 2-valve manifold with sight-glass & 1/4" SAE fittings anodized aluminium block body, oversized sight-glass for easy viewing the refrigerant flow high quality stainless steel gauge and high accuracy of reading
- Ideal for R32 R134a R410A R407C
- All hose are complied with SAE-J2196 standard standard.
Hose size:
- 1-Red: 1/4" Female SAE on straight end and 1/4" Female SAE on bent end
- 1-Blue: 1/4" Female SAE on straight end and 1/4" Female SAE on bent end
- 1-Yellow: 1/4" Female SAE on straight end and 1/4" Female SAE on bent end
Package includes:
- 1 x 3CFM Single-stage Vacuum Pump
- 1 x Gauge Set
- 3 x 4FT Blue Red Yellow Refrigerant Hose
- 2 x Adjustable Quick Fitting
- 1 x Toolkit
Note:
* When use R-410A function, you are ought to buy two extra adapters -1/4" Male SAE to 5/16" Female SAE, which not included in our product listing.
